Antoinette

The Valcourt Antoinette is a clean-lined wood fireplace with a large glass surface and sleek faceplate. Its guillotine door and spark screen slide effortlessly for easy loading, and it qualifies for Phase II of the EPA voluntary program, up to 70% cleaner than unqualified decorative models.

Specifications

• Fuel Type: Wood (dry cordwood, 16" recommended)
• Firebox Volume: 5.3 cu. ft.
• Max Log Length: 18" (loads across the width)
• Firebox Dimensions: 24 1/4" W × 21 3/4" H × 11 1/2" D
• Overall Dimensions: 48 7/8" W × 64 1/8" H × 30 3/4" D
• Shipping Weight: 523 lb (238 kg)
• Door Type: Guillotine, glass with steel frame
• Door Opening: 33" W × 21 1/4" H
• Glass Size: 29 3/4" W × 19 1/2" H (ceramic)
• Firebox Lining: Moulded refractory bricks, cast iron andirons
• Flue Diameter: 8"
• Chimney Type: CAN/ULC S629, UL 103 HT (2100 °F)
• Min Chimney Height: 15 ft
• Emissions: 4.2 g/kg
• EPA Status: EPA Phase II qualified (low mass)
• Safety Standards: UL 127, ULC-S610
• Mobile Home Approved: No
• Warranty: Limited lifetime

Clearances

Minimum clearances to combustibles from the installation manual (Canadian installation; side measurements from the door opening). Always confirm with the manual and local code before installing.

• Side wall: 8" from door opening on one side; 20" on the other side if walls on both sides
• Combustible side mantel / trim: 3" max depth, 8" min from door opening
• Combustible mantel shelf: 46" above fireplace base (6" deep) to 52" (12" deep)
• Minimum ceiling height: 84" (7') from base of fireplace
• Hearth extension: 16" in front, 8" each side of door opening
• Combustibles in front of fireplace: 48" from front of opening

Documents

• Installation & Owner's Manual
• Dimension Sheet
