Osburn
1700 Insert
1700 Insert
In stock
Regular price
$3,275.00 USD
Regular price
Sale price
$3,275.00 USD
Unit price
/
per
Couldn't load pickup availability
Like its larger counterpart Osburn 2000, the 1700 insert offers a revamped version of perfect size to provide ambiance and warmth. Give yourself a real haven of peace with an eco-friendly device whose average particle emission rate is prodigiously low at 1.26 g/h!
Inside and out, this insert is engineered from high-quality materials that put you at the center of a heating experience for many years: high-density bricks, a cast iron door, and a quiet blower for increased durability. Discover the different options to customize the look of your appliance, available in black or brushed nickel-plated: door overlays, faceplates, and faceplate trims.
Specifications
Appliance Performance
| Fuel type : | Dry cordwood (16" recommended) | |
| Recommended heating area-ft² : | 500 - 1,800 | |
| Overall firebox volume-ft³ : | 1.9 | |
| EPA loading volume-ft³ : | 1.44 | |
| Maximum burn time : | 6 h | |
| Maximum heat output-dry cordwood : | 65,000 BTU/h (19 kW) | |
| Overall heat output rate < : | 15,650 BTU/h (4.6 kW) to 23,300 BTU/h (6.83 kW) | |
| Average overall efficiency (dry cordwood) : | 70 % (HHV) | 75 % (LHV) |
| Optimum overall efficiency : | 78 % | |
| Optimum heat transfer efficiency : | 74 % | |
| Average particulate emissions rate : | 1.26 g/h | |
| Average CO : | 58 g/h | |
Manual and Dimensions
