Focus SBR

The RSF Focus SBR is one of RSF's most popular fireplaces, built around the Smart BurnRate system, a fully automatic air control that makes it easy to run and very efficient. It is EPA 2020 certified at 1.4 g/h, with air-assisted easy light-up, plenty of heat and slow, lazy flames.

Certified for use with a 7" ICC EXCEL chimney only.

Specifications

• Fuel Type: Wood (cordwood)
• Max Heat Output: 10,000 – 50,000 BTU/h
• Efficiency: 66% EPA average (HHV), 75% optimal (LHV)
• Firebox Volume: 2.6 cu. ft.
• Max Log Length: 22"
• Framing Dimensions: 45" W × 44 1/4" H × 24" D
• Shipping Weight: 562 lbs
• Door Type: Black single door; louvers or clean-face kit
• Glass Size: 24 1/4" W × 13 1/4" H
• Flue Diameter: 7" ICC EXCEL chimney; masonry with 7" certified stainless liner
• Outside Air: 4", meets R2000
• Combustion Technology: Smart BurnRate (non-catalytic)
• Emissions: 1.4 g/h
• EPA Status: EPA 2020 certified
• Mobile Home Approved: Yes

Clearances

Minimum clearances to combustibles from the installation manual (Canadian installation; measured from the firebox opening unless noted). Always confirm with the manual and local code before installing.

• Side wall: 12" to side of firebox opening
• Combustible mantel: 12" max depth; 20" above top of firebox opening (0–6" deep) to 26" (12" deep)
• Minimum ceiling height: 7' (84") from base of fireplace with sealed enclosure; 6' (72") with vented enclosure
• Standoffs (sides, back, top): 0"
• Hearth extension: 20" in front, 42" min total width centred on opening

Documents

• Owner's Manual
